PRODUCT PARAMETERS
Description
Product Introduction
XINTAO Ceramic pall ring has excellent acid resistance and heat resistance. It can resist to corrosion of various inorganic acids, organic acids and organic solvents except hydrofluoric acid, and can be used in high or low temperature conditions. Consequently the application range is very wide. It can be used in the drying columns, absorbing columns, cooling towers, scrubbing towers and actifier columns in chemical industry, metallurgy industry, coal gas industry, oxygen producing industry,etc.
Technical Parameter:
|
Diameter (mm) |
D*H*T (mm) |
Surface area (m2/m3) |
Free volume (%) |
Number (pcs/m3) |
Bulk density (Kg/m3) |
Dry Packing Factor (m-1) |
|
25 |
25*25*3 |
220 |
73 |
54000 |
620 |
565 |
|
38 |
38*38*4 |
150 |
75 |
13400 |
570 |
356 |
|
50 |
50*50*5 |
120 |
78 |
6800 |
550 |
252 |
|
80 |
80*80*8 |
75 |
80 |
1950 |
520 |
146 |
Typical Application
a) Have excellent acid resistance and heat resistance.
b)It can resist to corrosion of various inorganic acids, organic acids and organic solvents except hydrofluoric acid.
c)Used in high or low temperature conditions.
d) Used in the drying columns, absorbing columns, cooling towers, scrubbing towers and actifier column in chemical industry, metallurgy industry, coal gas industry, oxygen producing industry, etc.
